GL-1850D Direct drive Bar tacking sewing machine
DETAILS

GL-1850

Bar tackig for various kinds of clothing such as suits,jeans and work clothes or for trousering,silicon oil supply device guarantee the perfect stitch made sewn by cotton or synthetic thread.Adopt simple V type belt amderate organization,raise reliability and service life of products. New design of large cam reduces the impact of inflexion.You can get a desired stitch by using different cam.


GL-1850D

Functional advantages of high-speed direct-drive bar tacking machine:
Using direct drive servo motor, low noise and low vibration
Eliminates the stopping cam system, which can reduce mechanical failures and parts loss rate. Eliminates the motor belt driving system to make the sewing speed more stable and higher.

Specification:

Max Sewing Speed:2000rpm

Needle:DPx5 (#14)

Pattern Size:Y30mm X 40mm

Stitch Length:0.1-10mm

Work Clamp Height: Standard 13mm

Hook:Shuttle hook
