1.关键运动零部件表面GIC高硬度自润滑处理，减小机器零部件磨损，延长机器使用寿命。

Keyparts:Key parts with GIC high hardness coating process,extend the mahcine life.

2.配置钢结构台板，自带下滚轮，局部移动方便，机器整体运行平稳，降低噪声减小振动。

Steel structure table&stand :Steel structure stand and table with wheels,convenient for moving the machine,performing steadily,low noise,low bibration.

3.自动抬压脚、气动抬拖轮、自动机针冷却、自动剪线装置、吸入线头式

 Automation:Auto presser foot lifter,AutoPneumatic puller lifter ,needle cooler,Auto thread trimmer,inhalation ofthread.

4.可以选择内置拖布轮和履带式拖布轮，相辅于机器转速的同步提高稳定，出线辫顺畅，履带式拖轮，厚薄料通用，适用性强（MPF/EPF）

Puller:Select to Built-in pullers and crawler-type pullers, synchronizing to the machine,the line will run smoothly. Crawler-type pullers, both of thin material and thick material, More applicability.(MPF/EPF)

5机器润滑方式1.下轴底坐 机臂为贮油飞润滑，2.上主轴油泵自动加油

1.     Automatic refueling:Lubricating system:

a. Spatter lubricatingin machine base.

b.Auto lubricating of the upper shaft.

■产品规格 ∣Specifications:

最高缝速:4300针/分  Max speed: 4300 rpm/min

送料量:2.6mm-4.8mm/针 Stitchlength:2.6mm-4.8mm

针数:二/三针 Needle quantity:2/3needles

采用机针:TVx5#21   TVx64#14 Adopt needle:TVX5 21#,TVX64 14#

马达:伺服电机  国产下挂式 节能电机  Motor:Servo motor,domestic hanging motor

MH：贺欣全功能下挂马达  MH；HOHSING full-function hanging motor

MS：普通下挂节能马达  MS:Ordinaryunder hanging servo motor

GL-988L-MPF/CV-T-MH 三针(薄料气控皮带式拖轮)-(thin material pneumatic control belt puller)

GL-988-PLA/CV-T-MH 三针(机械式直驱拖轮)-(mechanical direct drive puller)

GL-988XH-PLA/CV-T-MH三针(厚料机械式直驱拖轮)-(thick material mechanical direct drive puller)

GL-988XH-MPF/CV-MH 三针(厚料气控皮带式拖轮)-(thick material pneumatic belt control puller)

GL-988XH-MPF-T/CV-T-MS 三针（厚料气控皮带式拖轮）-(thick material pneumatic belt control puller)
