This is a special flower machine, the back of the fuselage is equipped with scissors, can make a small round hole embroidery effect; Widely used in women’s skirts, shirts, handkerchiefs, ties, tablecloths, sheets embroidery; Applicable fabrics, silk, chiffon, electric yarn, hemp material
GL-1721P PICOTING MACHINE
FOR MAKING BLOUSE, SHIRTS, TIE, BEDSHEET, SCRAF, TIE ETC,
GL-1721P PICOTING MACHINE OPOTIONAL SETING
• HOOK：CHINESE/ JAPANESE KOBAN QUALITY( OPTIONAL)
• OLIINGWAY ：MANUAL / AUTO-OILING
• HOLE SIZE CHART
| MAN NEEDLE SIZE AND STITCH SIZE | Main needle PKZX1 | Inner dia mm | Outer diameter mm |
| #1 | 1 | 2.0 | |
| #2 | 1.5 | 2.5 | |
| #3 | 2 | 3.0 | |
| #4 | 2.5 | 3.5 | |
| #5 | 3 | 4 |
The related m machine model No
1GL-1721 ( the standard setting for making hole stitch ）
2GL-1721P（ with the puller device for making hole stitch ）
3GL-1721PK ( with the puller device and cutter device for making picoting edge cutting stitch ）
specification
| Stitch speed | 1400 stitch /Min |
| Oil supply system |
Manual oil lubrication Auto oil lubrication |
| Stitch Length | 3-5mm |
| Need bar stroke |
Guide needle 33.4mm Main needle : 16.5mm |
| Presser lifter | 5MM |
| Needle |
(1) STITCH NEEDLE :DBX1 (2) Guide needle : PKGX 8 (3) Main needle : PKZ X1 (#1-#5) |
