GL-810D/820D Direct Drive Single/double- needle post bed sewing machine
DETAILS
FEATURES
Single-needle post bed sewing machine;.It adopts sliding bar thread Take-up and vertical rotary hook.Push-button stitch regulator and lever styleback-sewing device,make the machine operating easily.It is designed with post-bed and provided with roller presser foot to perform sewing at wide space under arm.
The machine suitable for sewing shoes,bag and hats ets.
| Model | Feeding | Max sewing speed (R.P.M) | Needle | Stitch length (mm) | Presser foot lifting height (mm) | Auto trimmer, auto presser foot lifting, auto reverse feeding, auto bar tacking (Pneumatic) |
Packing size (cm) |
G.W./N.W. (kgs) |
| GL-810D/820D | teeth feeding | 2000 | DP*5 14-19# | 7 | 15 | no | 64*26*56 | 42/37 |
| GL-810/820-D3 | teeth feeding | 2000 | DP*5 14-19# | 7 | 15 | yes | 64*26*56 | 43/38 |
| GL-810/820 | teeth feeding | 1800 | DP*5 14-19# | 7 | 15 | no | 64*26*56 | 37/32 |
