Working space: 258*110mm

Advantages:

1. The full synchronized binder using a synchronous motion, the close fitting binding folder moves backwards and forwards with the feed mechanism to ensure constant accurate sewing of the binding tape;

2. A heavy duty triple feeding action by way of: bottom feed, needle bar feed and walking foot top feed, which combine together to produce high quality displacement-free seams;

3. The versatile narrow cylinder free-arm design allows binding on tight radius corners like: bags, gloves, shoes, holster, knife sheaths, and filters etc.

4. Fewer bobbin changes due to the large hook (40% more bobbin capacity than standard hook);

Applications:

Suitable for working on tubular or pre-attached articles:
1. Standard sewing work on leatherware, bags and leather crafts;
2. Binding of shoes, bags and leatherware with leather, imitation leather or textile tape;
3. Piping work on bags, suitcases and upholstery;
4. Decorative stitching in small leather goods

Specifications:
Max. Sewing Speed: 2200 rpm
Hook Type: 1.4 times large rotary hook
Presser Foot Lift: 14mm
Needle bar stroke: 33.4 mm
Needle System: 134–17 DP×17 Nm 80–100
Thread take-up lever stroke:59.6 mm
Stitch Length: 0-6mm
Bobbin size: Outside Dia. 22mm, Height 10mm
Max. top feed stroke: 7 mm
Cylinder arm diameter: 46.5mm
Working space: 257mm (length) x110mm( High)
