Advantages:
1. The sewing machine arm has been extended (complete casting, not a cut and piece extended arm) to give approximately 635 mm clearance, which is very useful when sewing larger items, for example: parachutes, sails, tents, covers, ect;
2. Its powerful and steady feeding action enables you to sew multiple ply of heavy weight material with a true and even stitch;
3. The presser foot has an extra high lift and can go up to 23mm, allowing for a large range of extra heavy weight material or bulky items to be used;
4. A stitch length of up-to 11mm is possible (which in sewing machine terms, is big) and the machine has a reverse stitch lever as standard;
5. The special extra large shuttle hook and bobbin capacity reduces the number of bobbin changes and offer high efficiency in sewing products using extra thick thread up to metric size 7* (=V415, T-400, 1300dx3);
Applications:
sails, parachutes, tents, sheets, mattress, space suits, textile webbing slings, tarpaulins, canopies, outdoor awnings, sleeping bags, military products, marine and furniture upholstery, automobile upholstery, industrial safety products, hot air balloon, umbrella, shade sails, backpacks, field covers, and heavy bulky products.
Specifications: |
|||
Max. Sewing Speed: |
800 rpm |
Hook Type: |
HAD-204 Barrel Shuttle Hook |
Presser Foot Lift: |
23mm |
Needle bar stroke: |
56 mm |
Needle System: |
794 (DYx3) needle,-#230 |
Max. Thread size |
#7, V415, 1300dX3, T-400 |
Stitch Length: |
0-11mm |
Bobbin size: |
Outside Dia. 24mm, Height 30.5mm |
Take up stroke: |
96 mm |
|
|
Working space: |
635mm (length) x190mm( High) |
Motor: |
200-240V, 750W AC Servo motor |
