Features:

GL-05 double-needle moccasin machine is suitable for sewing the mark thread of shoe upper. 12 different upper patterns can be sewn by changing cams and components, and adjusting the feeding gear and needle. (For specific patterns, please refer to The following figure).

This moccasin machine has a stable structure, simple operation in the process of changing patterns, and patterns can be changed according to specific needs. In addition, you can also adjust the corresponding knob to produce the sewing effect of the side surface wrinkles, which can be adjusted according to your own needs.

GL-05 often stitches E-shaped, crossed, square and other patterns. The lock stitches and stitches are even and beautiful. It is suitable for leather shoes, casual shoes, Harlan style and other shoes. Surface sewing.

The machine is equipped with corresponding manuals and common tools at the factory, and the corresponding pattern cam can be configured according to specific requirements.

Technical data:

Sewing speed: 400 RPM

Stitch: double- thread lockstitch

Stitch length: 0-8mm

Two- needle distance: 6mm

Needle: DD*1

Motor: 750W/ 220V/50-60hz

Machine net weight:180 kgs

Machine gross weight:240kgs

Packing size: 131*78*144cm
