Machine features：

1.It needs two sets machines to finish the work.By changing the mold parts and slots, it can be loaded with other size buttons;

2.The mechanical travel: the down mould does not move, the upper mould punching down to snap.

3.Automatic feeding button to the upper and lower mold, hand-free to put the button, avoiding the risk of hurting the hand;

4.With automatic buffer device, it can be suitable for different fabric thickness without adjusting the mold height.

5.The snapping speed is 4-6 times higher than ordinary button snap machine, one day it can snap buttons at 15000-35000 pcs;

6.It has two molds for punching: Single punching or continuous punching ,suitable for different workers’ demand.

7.It is equipped with anti- injury hand sensor, the sensor height is adjustable from 5-15mm

Voltage：220 V 50/60 Hz

Working depth：60 mm

Working speed：160 PCS/min

Machine weight：75 Kg

Machine size：480×480×1280 mm

Motor type：Servo motor

Application：plastic snap fasteners
