GL-600FA
DETAILS
| Feature : |
| Automatically Cooling when the machine is switched to power off. |
| Equipped with the flexible wheel for convenient mobility. |
| Continuous fusing system increases work efficiency. |
| Heating equipment controls heating system for smooth operation. |
| Electronic thermostat and the special-made heating equipment minimize the temperature differences |
| Equipped with the special linear guidance belt to prevent the belt from warping, and having longer duration of the belt. |
| Specification | |
| Model | GL-600FA |
| Power Supply | 1P/220V 3P/380V |
| Motor Power(kw) | 0.04 |
| Heater(kw) | 5.2 |
| Use Pressure(Mpa) | 0.1~0.3 |
| Temperature(C) | ordinary temperature~200 |
| Fusing Width(mm) | 600 |
| Fusing Time(Sec) | 10~34 |
| Pressure System | Pneumatic (Must Use Air Compressor) |
| LxW*HDimensions(mm) | 2100x1100x1050 |
| LxWxHPacking Volume(mm) | 1360x1230x1240 |
| N.W/G.W(kg) | 260/330 |
