This machine is specially designed for elastic attaching.

The mechanical belt feeder is beautiful in appearance, fixed on the machine head, and equipped with sewing machine 1 to 1, with good feeding accuracy, which makes the stitched fabric wrinkle evenly, reduces manual working intensity, and improves working efficiency by 2 times.

Applicable type of sewing machine: overlock sewing machine

Belt feeding size: 50mm

Installation form: fixed body

Synchronization mode: Sewing machine synchronization

Transport form: tension transport

Technical data:

Sewing speed: 5000RPM

Needle system: DCx27 11#

Number of needles: 2

Number of threads: 4

Presser foot lifting height: 6mm

Stitch length: 0.5-3.8mm

Stitch width: 5mm

Differential feeding rate: 0.7-2mm

Packing size: 47*36.5*50cm
