Durm type interlock sewing machine with atuo trimming  (the electric)

The machine is suitable for sewing any clothing, especially suitable for women T-shirt lead cover seam, baby clothing , and other sewing work roll sleeve. head circumference is 176mm. Adopt to external type direct drive energy saving motor, to achieve the accuracy of the machine when start to work and stop quickly, what’s more, it saves about 60% of energy than ordinary machines. automatic presser-foot lifting, automatic top & under threaded trimming, and automatic speed limiting. low investment, and upgrade the production efficiency.

Technical data:

Sewing speed: 4000RPM

Needle system: UY128GAS 9-14#

Number of needles: 3

Number of threads: 5

Gauge set: 356 or 364

Cylinder bed diameter: 17.6cm

Presser foot lifting height: 5.5mm

Stitch length: 0.5-1.3mm

Stitch width: 4.4mm

Differential feeding rate: 0.7-2mm

Packing size: 61*40*63cm

Machine weight: 57.6/50kgs
