It is used to load elastic band (with right side cutter, back puller,cloth scraps absorption and fabric stretching and controlling device) on the tubular goods,such as Looped waistband. The sewing operation continues while the edge of waist (under the elastic band) is trimmed by the right side cutter, the cloth scraps will be sucked into the waste bag through the suction pipe.

Technical data:

Sewing speed: 5000RPM

Needle system: UY128GAS 9-11#

Number of needles: 3

Number of threads: 5

Gauge set: 356 or 364

Presser foot lifting height: 5.5mm

Stitch length: 1.4-4.5mm

Stitch width: 4.4mm

Differential feeding rate: 0.7-2mm

Packing size: 61*40*63cm

Machine weight: 57.6/50kgs
